DiColor U6 LED Display

Rentals/Manufacturers/Video/DiColor

DiColor U6 LED Display.

LED Display Panel

Details

This 16:9 Ratio feature a total of 60 Di-Color U6 L.E.D. Video Panels. 10 Panels across horizontally and 6 Panels down vertically. (16.4’ x 9.84’) The rental of this video wall comes complete with all the necessary hardware and processing components to power the wall as well as the transmission of your video signal input to the video wall itself. The items are listed below.
FEATURES
  • Indoor 6.4 mm pixel pitch SMD LED display
  • Lightweight – Each cabinet weighs only 12.5 kg (about 27.6 lbs)
  • Thin design – Cabinet thickness 87 mm deep (about 3.4 inches)
  • Plug and play design - The cabinets are easy and quick to assembly without any special tools. It is an ideal LED display for rental applications.
  • Easier to remove center modules than conventional coffin lock systems
  • Reduced transportation and installation costs
  • Good refresh rate
  • High grayscale
  • High contrast
  • Vivid video display
  • Low power consumption
  • Low noise output
SPECIFICATIONS
DESCRIPTIONINDOOR SMD 6MM LED
PANEL RESOLUTION80*80
CABINET SIZEW: 512mm H : 512mm D : 100mm
PITCH SIZE6.4mm
BRIGHTNESS>1600 cd/m²
IPIP30
POWER SUPPLY110V-240 V
RESOLUTION WIDE720
RESOLUTION HIGH480
SYSTEM WEIGHT LBS.1,485
SYSTEM WIDTH FT15.12
SYSTEM HEIGHT10.08
