XA20 sx8.5 BERM-K3 ENG Lens.
Cameras
Details
The Fujinon XA20sx8.5BERM-K3 ENG Lens is a 8.5-170mm lens, designed to provide 2/3" format cameras with a wide to super telephoto angle-of-view. The lens has a 20x zoom ratio, and a 2x extender effectively doubles the focal range. An ergonomic, digital servo zoom control is also included. Internal focusing minimizes the effects of lens breathing, which ensures a more consistent focal length when adjusting focus. Fujinon's QuickZoom technology improves zoom speed to 0.7 seconds end to end. With the push of a button, QuickZoom facilitates a rapid shift to the telephoto end to check focus. Releasing the button automatically returns the lens to the previously selected focal length.
FEATURES
- 8.5-170mm zoom lens with 20x zoom and 2x extender for 2/3" format
- Fast f/1.8 Max Aperture at 8.5-113mm and f/2.7 at 175mm
- Manual focus and digital servo zoom
- Innerfocus and QuickZoom technology
SPECIFICATIONS
| Sensor Compatibility | 2/3" (16:9) |
| Focal Length | 8.5 to 170mm |
| Built-In Extender | 2x |
| Zoom Ratio | 20x |
| Angle of View 16:9 | Wide: 58.85 x 35.18° (H x V) |
| Tele: 3.23 x 1.82° (H x V) | |
| Maximum Aperture | f/1.8 to 2.7 |
| Filter Thread | M82 x 0.75 mm |
| Minimum Focus Distance | From : 3.61' / 1.1 m |
| Minimum Object Distance | 2.95' / 0.9 m |
| Dimensions | 3.3 x 7.1" / 85.0 x 180.8 mm (ø x L) |
| Weight | 3.48 lb / 1.58 kg |
- Fujinon XA20 Lens User Manual
