OCTOBER 2020.
Monthly Specials
Specials Valid from October 1st, 2020 through October 31st, 2020.
Darkfx Spot 670.
UV Fixture
Details
The Antari DarkFX Spot 670 is an efficient high output low power consumption UV LED spot that delivers a peak wavelength of 365nm and radiant flux output of 6760mW at full intensity with minimum visible light. This ensures all UV reactive materials, art, amusement park displays, and signage reflects perfectly with stunning bright and vivid colors.
It features (9) 1.9W high power UV LEDs, a 15-degree narrow beam angle, special optics to prevent wear degradation from high UV exposure, flicker free operation for TV and FILM, an aluminum housing, manual and DMX controllable, 5pin DMX and Locking Power Cable in/out connections, dual adjustable/removable mounting yokes, 4 button control panel, and a multi-voltage universal auto switching power supply (100-240V) 50-60Hz).
Ultraviolet light is commonly categorized as being between the wavelengths of 100 nm and 400 nm. We can certainly see the effects of ultraviolet light through fluorescence in objects illuminated by UV sources, but real UV light is invisible
- High Efficiency UV LED Spot.
- 15-Degree Narrow Beam Angle.
- 365nm Peak Wavelength with Minimum Visible Light.
- 6760mW High Output at Full Intensity.
- Special Optics to Prevent Wear Degradation from High UV Exposure.
- Flicker Free Operation for TV and FILM.
- AC100-240V 50-60Hz
- 19.1W @110VAC / 18.8W @220VAC Max Power Consumption* *LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
| Optics: | 15 Degrees |
| Peak Wavelength: | 365nm |
| Radiant Flux Output: | 6760 mW |
- Manual and DMX 512 Control
- 4 Button Control Panel
- 5pin DMX In/Out
- Locking Power Cable In/Out
| Length: | 8.0” (205mm) |
| Width: | 4.9” (125mm) |
| Vertical Height: | 4.9” (125mm) |
| Weight: | 5.82 lbs. (2.64 kg) |
- Risk of exposure to ultraviolet radiation, avoid direct eye and skin exposure.
- DO NOT operate fixture without external cover and protective lens installed.
- DO NOT operate fixture with damaged external cover and/or protective lens.
- CE | IP20
- Antari Darkfx Spot 670 User Manual
Specials Valid from October 1st, 2020 through October 31st, 2020.
UV Wash.
UV Fixture
Details
Black lights just got lighter with the introduction of Elation Professional's new UV Wash, an ultraviolet fixture designed for mobile use and rentals.
Weighing just 11 pounds, the UV Wash is much more lightweight and transportable than traditional black lights. Thats because the UV Wash uses a compact fluorescent UV lamp instead of the typical gas discharge lamps, which require a heavy transformer to operate.
Through the years, black lights have remained one of the most universal special effects for club and stage use -- and they keep getting better with new, improved features. Now, with the UV Wash, you can achieve great ultraviolet effects without having to lug around an awkward light with a transformer that weighs a ton, thanks to its compact fluorescent UV lamp.
In addition to using a fluorescent UV lamp, the UV Wash has been given other roadworthy features that make it ideal for pros on the go. Rugged and durable, it has a strong aluminum case with a compact design. A 5mm shatterproof glass cover protects the lamp from breaking, so you never have to worry about popping a tube during setup or transportation.
The UV Wash is extremely portable, making it the perfect black light choice for touring musicians, stage productions and the rental market. It really brings out the whites of peoples eyes, teeth and clothes in low-lit environments, creating a dramatic glow-in-the-dark effect.
Another advantage of the UV Wash is that its 100-watt, 120-volt lamp operates on low amperage, saving energy. Yet, it's still bright enough to give full coverage at 25 feet. Reflective glass mirrors serve to amplify the fixtures brightness and widen its span without drawing any additional power. The lamp itself has an incredibly long life expectancy of 1,000 hours.
Other practical features of the UV Wash include die-cast aluminum sides, adjustable hanging bracket, convection-cooled vents, 2-amp fuse breaker, and a grounded Edison socket. The UV Wash measures a compact 14 in. L x 10 in. W x 7 in. H, and weighs just 11 lbs. Replacement Lamp: LL UVW100.
- 100 Watt output
- Wide coverage
- Glass Reflectors
- Shatter proof front glass cover
- Aluminum Case Design
- Fluorescent UV lamp
- Aluminum Die Cast sides
- Aluminum case
- Aluminum 1 arm Yoke
- Convection cooled vents
- 4mm Reflective Glass mirrors
- 5mm Shatter proof Glass cover
| Dimensions | 14"x 10"x 7" |
| Weight | 11 lbs |
| Fuse | 1amp GMA |
| Voltage | 110-120v |
| Lamp | LL-UVW100 (120v, 100w, 1000hrs |
- Elation UV Wash User Manual
